4
CHECKS AND MAINTENANCE
49
GB
OIL FORK
The procedure for changing the oil in the
forks is provided only for information.
We recommend having the operation
performed by a BETAMOTOR authorized
workshop.
REMOVING LEGS
To replace, proceed as follows:
Position the vehicle on the central bike
stand.
Remove the front wheel.
Remove the mudguard, the brake caliper
and brake disc cover.
Loosen the screws 1 and pull off the stems.
OIL REPLACEMENT RIGHT LEG
Unscrew upper plug 2.
Unscrew fi xing lock nut and take off the
plug.
Unscrew the fi xing screw of the cartridge
positioned under the fork leg, and extract
the cartridge.
1
2
