Beta EVO 2T Handbook

3
ADJUSTMENTS
30
GB
ADJUSTING FORK
ADJUSTING THE REBOUND
DAMPER
The hydraulic brake unit in extension
determines the behaviour in the extension
phase of the fork and can be adjusted us-
ing screw 1. Turning clockwise increases
the action of the brake in extension, while
rotating counter-clockwise decreases the
action of the brake in extension.
For standard calibration, refer to page
11.
1
ACCELERATOR
ADJUSTING THE IDLE SPEED
In order to perform this operation correctly,
we advise you to do it when the engine
is hot, connecting an electric revolution
counter to the spark plug wire. Then use
a screwdriver on register screw A to cali-
brate the minimum with 900÷1000 rpm.
A
HANDLEBAR
The handlebar can be adjusted by rotating
it back and forth.
- To adjust the handlebar loosen screws 1.
- Position the handlebar according to
requirements.
- Tighten to the torque indicated.
1
20Nm

Beta EVO 2T Specifications

General

Displacement	249 cc
Cooling System	Liquid cooled
Transmission	6-speed
Bore x Stroke	66.4 mm x 72 mm
Clutch	Wet multi-disc
Dry Weight	67 kg
Engine Type	2-stroke single
Front Suspension	Telescopic fork
Rear Suspension	Monoshock
Front Brake	Single disc
Rear Brake	Single disc
Fuel Capacity	2.5 liters
Frame	Aluminum
