Beta EVO 2T Handbook

4
CHECKS AND MAINTENANCE
37
GB
REPLACEMENT: VEHICLES WITH
WATER DRAIN ON HEAD COVER
Position the vehicle on a fl at base and in
a stable manner.
Replacement of the coolant must take place
when the engine is cold.
1) Unscrew cap 1.
2) Place a container under screw 2.
3) Unscrew the screw 2.
4) Drain the liquid.
5) Tighten screw 2 applying the specifi c
washer.
6) Unscrew drain screw 3 and fi ll until the
liquid starts to overfl ow the screw.
7) Tighten screw 3.
8) Place the vehicle as shown and pro-
ceed to fi lling.
9) Reapply the loading cap 1.
The amounts of liquid are shown on page
10.
1
3
10Nm
2

Beta EVO 2T Specifications

General

Displacement	249 cc
Cooling System	Liquid cooled
Transmission	6-speed
Bore x Stroke	66.4 mm x 72 mm
Clutch	Wet multi-disc
Dry Weight	67 kg
Engine Type	2-stroke single
Front Suspension	Telescopic fork
Rear Suspension	Monoshock
Front Brake	Single disc
Rear Brake	Single disc
Fuel Capacity	2.5 liters
Frame	Aluminum
