Beta EVO 2T Handbook

4
CHECKS AND MAINTENANCE
41
GB
1
CARBURETOR
DRAINING THE CARBURETOR
FLOAT CHAMBER
If the carburetor tank needs to be emptied,
proceed as described. Perform the opera-
tion once the engine is cold.
Turn the fuel cock to OFF position (see
page 20).
Place a cloth under the carburettor in order
to collect the fuel that comes out.
Loosen screw 1 and drain the fuel until
complete emptying of the tank.
Tighten screw 1.
WARNING
Fuel is fl ammable and toxic and must be
handled with great care. Never work on
the fuel system near heat sources or open
fl ames. Always allow the engine to cool
down before working on the fuel system.
Wipe off any excess fuel with a rag. Mate-
rials soaked in fuel are also fl ammable. In
case of ingestion or contact with sensitive
parts of the body immediately seek medi-
cal attention. Fuel is to be disposed of as
prescribed by law.

Beta EVO 2T Specifications

General

Displacement	249 cc
Cooling System	Liquid cooled
Transmission	6-speed
Bore x Stroke	66.4 mm x 72 mm
Clutch	Wet multi-disc
Dry Weight	67 kg
Engine Type	2-stroke single
Front Suspension	Telescopic fork
Rear Suspension	Monoshock
Front Brake	Single disc
Rear Brake	Single disc
Fuel Capacity	2.5 liters
Frame	Aluminum
