GENERAL INFORMATION
17
GB
Key to colours
Bi = White
Ve = Green
Ma = Brown
Vi = Purple
Bl = Blue
Ne = Black
Gi = Yellow
Rs = Red
Ar = Orange
Az = Sky-blue
Ro = Pink
Gr = Grey
LEGEND ELECTRICAL DIAGRAM RACE VERSION
1) Headlamp (double fi lament bulb) 12V-35/35W
2) Horn 12V
3) Horn button
4) Engine stop button
5) Switch for change mapping (yellow)
6) Light switch (black)
7) Tail light with bulb 12V - 3W
8) Generator
9) Pick-up
10) H.T. coil
11) Electronic control unit
12) Regulator 12V
13) Thermal switch
14) Electrofan
15) Frame earth
