• Frequency Group (GR) / Channel (CH)
Here you can select a channel or frequency from a predefined
frequency group according to the respective region code (A, B,
C, D or E).
Press the rotary switch  to enter the sub-menu. Turn the rotary
switch  to the left or right to select the requested group. You
can select between robust and standard frequency groups. In a
robust group there are less channels with a bigger frequency
spacing. This prevents interference of the transmitters among
each other.
In a standard group there are more channels with a closer
frequency spacing, which can cause interference of the
transmitters among each other.
We recommend using a robust frequency group.
From the information at the bottom you can see how many
channels are in the appropriate group. Press the rotary switch  to
confirm.
Then turn the rotary switch  to the left or right to select the
requested channel from the previously selected group. From the
information at the bottom you can see the appropriate frequency.
Press the rotary switch  to confirm.
As a user you can generate groups (“User Groups”) with
appropriate channels and frequencies by using the “Chameleon”
software, with which you can enter the groups into the receiver.
These groups are marked with a “U”.
▲ Name: Sample
• GR/CH: xx / xx
▼ Freq: xxx.xxxMHz
Robust 470 - 614
• GR/CH: xx / xx
xx Channels (xxx - xxx MHz)
• GR/CH: xx / xx
Freq: xxx.xxx MHz
1
1
1
Select the “Frequency Group (GR) / Channel (CH)” submenu
Select the “Frequency” submenu
Select frequency
Select “Frequency Group (GR)”
Select “Channel (CH)”
xx
xx
• Frequency
Here you can manually select a frequency between 470 and
789 MHz regardless whether it is in a group or not.
If you select a frequency manually, it is displayed in the default
screen by “GR / CH --/--”.
Press the rotary switch  to enter the sub-menu. Turn the rotary
switch  to the left or right to select the first three numbers of
the requested frequency. Press the rotary switch  to confirm.
▲ GR/CH: xx / xx
• Freq: xxx.xxxMHz
▼ Quick Scan
• Freq: xxx.xxxMHz
1
1
xxx
