BIFFI F01-2000 ELECTRIC ACTUATOR
INSTRUCTION AND OPERATING MANUAL
The warning condition occurs when a variable
reaches a critical value and/or a maintenance
action is required, but the actuator control
functions are still available. The alarm
condition occurs when a variable is out of the
acceptable range and the actuator control
functions are not available.
The alarm and warning lists only contain
the present alarms and warnings. When the
fault condition disappears, the corresponding
alarm or warning disappears from the list.
A reset routine is provided to clear the
type of alarm/warning that are memorized
(over-torque, jammed valve,etc.).
DESCRIPTION OF VARIABLES AND REPORTS
torque output torque in % of the nominal torque stated in the NAMEPLATE menu
motor speed RPM of electrical motor
main voltage voltage (V) and frequency (Hz) of mains
current current (A) absorbed by the motor
temperature temperature (°C), inside the electronic compartment
time present time
date present date
alarm list of present alarms (see paragraph 12.10, Diagnostic messages)
warning list of present warnings (see paragraph 12.10, Diagnostic messages)
Ktemp temperature factor
mot temp temperature (°C) of the electrical motor
term temp temperature (°C) inside the terminal board compartment
log status data logger status (off, ready, in progress: E: event number - n° of memory cycle
or R: sample number - n° of memory cycle)
wireless report Bluetooth™ interface status (ready, not ready)
node report report of bus interface card (only present if the bus card is present)
(see the relevant instruction manual)
FDI report report of FDI function (only present if the LonWorks bus card is present)
(see the relevant instruction manual)
base report base card report
- card code
- manufacturing week and year
- electrical diagram, etc.
term report terminal board card report
- card code
- manufacturing week and year
- electrical diagram, etc.
Ain/Aout report Ain/Aout card report (only present if the card is present)
- card code
- manufacturing week and year
- electrical diagram, etc.
