BIFFI F01-2000 ELECTRIC ACTUATOR
INSTRUCTION AND OPERATING MANUAL
6�3 ENTERING THE VIEW MODE
The existing actuator configuration should
be checked before commissioning. The
parameters are configured in factory
according to a standard setting, or to customer
requirements. In view mode, no password is
requested, but no change of parameters can
be made.
• Ensure the electrical main power is applied.
• Move the 3-position selector to OFF and then
simultaneously press OPEN/YES and STOP.
• The display shows the present language.
Press YES to confirm or NO to scroll the list
of available languages. Press YES to select a
new language. Press YES to confirm.
• Press NO to scroll the list of available menus
(actuator set-up, nameplate, valve data,
maintenance) and then press YES to select
the desired menu.
• Press NO to scroll the list of available
routines and press YES to select the routine
where the parameter to be changed is
located.
• Press NO to scroll the list of parameters and
press YES to view the value.
6�4 ENTERING THE SET-UP MODE
To change the existing settings or to set the
stroke limits it is necessary to enter the correct
password.
• Ensure the electrical main power (or the
external auxiliary supply) is applied.
• Move the 3-position selector to OFF and then
simultaneously press OPEN/YES and STOP.
• The display shows the present language.
Press YES to confirm or NO to scroll the list
of available languages. Press YES to select.
Press YES to confirm the chosen language.
• Press NO when the message is
“VIEW MODE OK?”. Press YES to answer
prompt “ENTER PASSWORD OK?”.
• Enter password. Enter one digit at a time.
Press YES if digit is correct, press NO to
scroll the list of available characters and
then press YES when the character is
correct. Enter 4 digits. After entering the
last digit, the microprocessor checks the
password. If it is correct the messages
“PASSWORD CORRECT” and then
“SET-UP MODE OK?” appear. Press YES.
• Press NO to scroll the list of available menus
(actuator set-up, valve data, maintenance)
and press YES to select the desired menu.
• Press NO to scroll the list of available
routines and press YES to select the routine
where the parameter to be changed is
located.
• Press YES and NO to answer the prompt on
the display and change the parameter.
• If the password is wrong the message
“PASSWORD WRONG” appears and set-up
mode will not available.
6�5 EXIT FROM VIEW AND SET-UP MODE
The following conditions cause the exit from
view and set-up mode:
• Move the 3-position selector to LOCAL or
REMOTE.
• Answer YES when the display asks
“EXIT OK?”.
• Press YES and NO simultaneously.
• Automatic exit after 90 minutes without any
parameter change or view.
• Remove the electrical power from the unit.
All settings are automatically saved to a
non-volatile memory and retained also if the
electrical power is removed from the actuator.
All F01-2000 actuators are configured before
shipping with a standard default setting unless
alternatives were requested on order. In case
of difficulty during commissioning, the default
setting can be re-instated by the appropriate
function in the routine ”miscellaneous” of the
actuator set-up menu. The actuator returns to
its original configuration and commissioning
can be resumed.
