38
BIFFI
F01-2000 ELECTRIC ACTUATOR
INSTRUCTION AND OPERATING MANUAL
9�4 EXAMPLE OF SET-UP ROUTINE
9�4�1 Torque set-up
SELECT
LANGUAGE
ENTER
PASSWORD
SETUP MODE
OK?
ACTUATOR SETUP
CHANGE?
STROKE LIMIT
CHANGE?
TORQUE SETUP
CHANGE?
CLOSING TORQUE
55% OK?
CLOSING TORQUE
70% OK?
OPENING TORQUE
60% OK?
OPENING TORQUE
65% OK?
YES
YES
YES
YES
YES
YES
YES
YES
NO
NO
NO
NO
NO
TO NEXT
TO VIEW
MENU
To exit from SETUP menu press YES and NO
simultaneously or move the 3-position selector to
LOCAL or REMOTE
Press NO
until the
desired
valvue
appears
and then
press
YES
XXXXXX OFF
STOP NEXT?
DISPLAY
LOCAL
REMOTE
STOP
YES
OFF
3-POSITION
SELECTOR
37
39
