F02 Quarter-turn Electric Actuators
instruction and operating manual
ACTUATOR MODEL 63:
• Enter set up configuration: move switch SW3 to position ON (Setting function);
• Move switch SW4 to position 9;
• Move switch SW6 to position 0;
• Confirm by pushing ENTER pushbutton, SW5;
• When pushing SW5, the red led blinks for confirmation;
• Exit set up configuration (move switch SW3 to position 1) or proceed with the next
settings.
ACTUATOR MODEL 125:
• Enter set up configuration: move switch SW3 to position ON (Setting function);
• Move switch SW4 to position 9;
• Move switch SW6 to position 1;
• Confirm by pushing ENTER pushbutton SW5;
• When pushing SW5, the red led blinks for confirmation;
• Exit set up configuration (move switch SW3 to position 1) or proceed with the next
settings.
ACTUATOR MODEL 250:
• Enter set up configuration: move switch SW3 to position ON (Setting function);
• Move switch SW4 to position 9;
• Move switch SW6 to position 0;
• Confirm by pushing ENTER pushbutton SW5;
• When pushing SW5, the red led blinks for confirmation;
• Exit set up configuration (move switch SW3 to position 1) or proceed with the next
settings.
ACTUATOR MODEL 500/1.000:
• Size 500 or 1.000 is defined by the reduction gearing in the actuator;
• Enter set up configuration: move switch SW3 to position ON (Setting function);
• Move switch SW4 to position 9;
• Move switch SW6 to position 1;
• Confirm by pushing ENTER pushbutton SW5;
• When pushing SW5, the red led blinks for confirmation;
• Exit set up configuration (move switch SW3 to position 1) or proceed with the next
settings.
