BIFFI F02 User Manual

25
© Copyright by BIFFI Italia. All rights reserved.
A !@#$ INTERNATIONAL LTD. COMPANY
F02 Quarter-turn Electric Actuators
instruction and operating manual
• When pushing SW5, the red led blinks for confirmation;
• Open limit switch setting is now completed;
• Exit set up configuration (move switch SW3 to position 1) or proceed with the next
settings.
6.2.6 STROKING TIME SELECTION IN CLOSING
• Enter set up configuration: move switch SW3 to position ON (Setting function);
• Move switch SW4 to position 4;
• Move switch SW6 to positions 0-9 for the requested stroking time according to the table
below:
• Push ENTER pushbutton SW5 to confirm;
• When pushing SW5, the red led blinks for confirmation;
• The selected stroking time in closing is now set.
• Exit set up configuration (move switch SW3 to position 1) or proceed with the next
settings.
6.2.8 STROKING TIME SELECTION IN OPENING
• Enter set up configuration: move switch SW3 to position ON (Setting function);
• Move switch SW4 to position 5;
• Move switch SW6 to positions 0-9 for the requested stroking time according to the table
above;
• Push ENTER pushbutton SW5 to confirm;
• When pushing SW5, the red led blinks for confirmation;
• The selected stroking time in opening is now set.
• Exit configuration (move switch SW3 to position 1) or proceed with the next settings.
6.2.9 SETTING OF THE TORQUE LIMITING DEVICE IN CLOSING
Closing torque limits: from 40% to 100% of the nominal torque. The nominal torque
corresponding to 100% is set in-house and stated in the name plate menu.
The limit torque value can be set in the closing direction by simply rotating rotary switch
SW6 to the required position.
The limit torque value can be set in a range between 40% and 100% of the nominal torque
with steps of about 6%. Each step represents about 6,67% of the nominal torque value.
• Enter set up configuration: move switch SW3 to position ON (Setting function);
• Move switch SW4 to position 6;
• Move switch SW6 to positions 0-9 for the requested Torque value (in percentage) in
closing;
• Push ENTER pushbutton SW5 to confirm;
• When pushing SW5, the red led blinks for confirmation;
• The setting of the torque limiting device in closing manoeuvre is now complete.
• Exit set up configuration (move switch SW3 to position 1) or proceed with the next
settings.
Size Nominal Operating Time (secs 90°) at selected step
Torque
(Nm) 987 6543210
063638 1215 22304050607590
1251258 1215 22304050607590
250 250 8 12 15 22 30 40 50 60 75 90
5005008 1215 22304050607590
1000 1000 15 24 30 45 60 80 100 120 150 180
2000 2000 33 53 66 100 132 180 220 264 330 400
F02 operating time selection table
