BIFFI ICON-030 - Appendix B: ICON3000; ICON3000 AD; ICON3000 LP; Safety Instructions; General

December 2019
125
Installation, Operation and Maintenance Manual
VCIOM-08500-EN
Appendix
Appendix
Appendix B: ICON3000 / ICON3000AD /
ICON3000LP
Ex db h IIB T4 Gb / Ex h tb IIIC T135°C Db IP66/68
Ex db h ia IIB T4 Gb / Ex h tb IIIC T135°C Db IP66/68
B.1 Safety Instructions
B.1.1 General
This Appendix B supplemental to Installation, Operation, and Maintenance Manual
MAN-02-04-97-0713 and prescribes the Safety Instructions applicable to electric
actuators of Series ICON3000 / ICON3000AD / ICON3000LP either as a base unit or when
they are equipped with:
a. an additional entry mounted on the control compartment or when they
are equipped with an optional extension
b. additional entries or with an optional extension
c. an optional electronic card mounted on the terminal board compartment,
as shown in Figure B-3. The subject actuator is certied according to EN
and IEC standards 60079-0, 60079-1, 60079-7, 60079-11 and 60079-31
and EN ISO 80079-36, 80079-37, for protection type Ex db h or Ex db h ia
for gas group IIB and Ex h tb for dust group IIIC. The actuator is suitable for
installation in an ambient temperature range from -25°C (-13°F) to +60°C
(+140°F).
 WARNING
Installation, conguration, commissioning, maintenance, and repairs must be performed
by approved and qualied personnel only.
Both the base unit ICON3000 and optional extension are designed in accordance with the
applicable international rules and specications, but the following regulations must be
observed in every case:
• The general installation and safety regulations.
• The proper use of personal protective devices (glasses, clothing, gloves).
• The proper use of tools, lifting and transport equipment.
