BIFFI ICON-030 - Appendix E: ICON3000; Safety Instructions; General

December 2019
156
Installation, Operation and Maintenance Manual
VCIOM-08500-EN
Appendix
Appendix
Appendix E: ICON3000
Ex db eb h IIB T4 Gb / Ex h tb IIIC T135°C Db IP66/68
Ex db eb h ia IIB T4 Gb / Ex h tb IIIC T135°C Db IP66/68
E.1 Safety Instructions
E.1.1 General
This Appendix E is supplemental to Installation, Operation, and Maintenance Manual
MAN-02-04-97-0713 and prescribes the Safety Instructions applicable to ICON3000
electric actuators in sizes 010, 020, 030, 040, and 050 either as a base unit or when they are
equipped with:
a. an additional entry mounted on the control compartment or when they
are equipped with optional extension
b. additional entries or with an optional extension
c. an optional electronic card both mounted on the terminal board
compartment, shown in Figure E-3.
The subject actuator is certied according to EN and IEC standards 60079-0, 60079-1,
60079-7, 60079-11 and 60079-31 and EN ISO 80079-36, 80079-37, for protection type
Ex db eb h or Ex db eb h ia for gas group IIB and Ex h tb for dust group IIIC. The actuator
is suitable for installation in an ambient temperature range from -25 °C (-13 °F) to +60 °C
(+140 °F).
 WARNING
Installation, conguration, commissioning, maintenance, and repairs must be performed
by approved and qualied personnel only.
The ICON3000 is designed in accordance with the applicable international rules and
specications, but the following regulations must be observed in every case:
• General installation and safety regulations.
• The proper use of personal protective devices (glasses, clothing, gloves).
• The proper use of tools, lifting equipment, and transport equipment.
