BIFFI ICON-030 - Page 140

6
4
1 2 3
5
XTE3000
December 2019
132
Installation, Operation and Maintenance Manual
VCIOM-08500-EN
Appendix
Appendix
Figure B-5 Base Actuator
B.7.2.2 Base Actuator With Extension [A] on the Control Compartment
Extension [A] provides an additional entry for a cable or conduit connection or for
connection of an external ATEX-certied apparatus.
With reference to Figure B-6, the thread form/size for the entry is as follows:
Table B-5.
Figure B-6 Base actuator with extension [A] on the control compartment
Entry Standard Size
Optional
6 M25x1.5
3/4" NPT
Entry 6
