ADVANCED USE MANUAL DD700
2.5.7 Testing all inputs
It is possible to request the status of all slot inputs using the following
command:
LI<CR>
The terminal responds with the following string:
n1n2n3<CR><LF>
where:
n1 is 1 character which is the logical combination of the status (0
or 1) of the inputs (max. 2) on board the terminal. It can have
values between 0 (30H) and 3 (33H).
n2 is 1 character which is the logical combination of the status (0
or 1) of the inputs (max.4) on slot 1. It can have values from 0
(30H) to F (46H). If there is no slot 1, n2 will have a value of " - " (2DH).
n3 is a character which is the logical combination of the status (0
or 1) of the inputs (max. 4) on slot 2. It can have values from 0
(30H) to F (46H). If there is no slot 1, n2 will have a value of " - " (2DH).
