ADVANCED USE MANUAL DD700
MEM.ZERO+AUTOZERO
It adds to a previous variant of the ignition; after having applied the zero stored, if the
weight is within the minimum weighing is performed a self resetting, if the weight is
above the reset is not altered
The authorities of zeroing devices remains unchanged and is always zero based
sampling.
Manual
management
of fields
NO, YES
See the Using the terminal chapter in the User manual.
3.6.3 Setup Menu/ANALOGUE scale/Configurations/Secondary scale
The terminal can manage 2 different units of measure at the same time for each scale (max. 4 units of
measure).
3.6.4 Setup Menu/ANALOGUE scale/Analogue scale parameters
Conversion
speed
It is possible to view (but not edit) the number of conversions that the A/D converter
performs per second.
3.6.5 Setup Menu/Scale/Sampling/View data
The sampling data (Reset, Full Scale, 1st intermediate point, 2nd intermediate point) is displayed either
in weight, according to the current unit of measurement, or in internal conversion points.
3.6.6 Setup Menu/DIGITAL Scale
Number of
Cells
It is possible to view (but not edit) the number of conversions that the A/D converter
performs per second.
Baud Rate
Baud Rate
3.6.7 Setup Menu/Scale/Test
View Points
With analogue scales it is possible to view the number of internal points of the
converter.
View weight
The current weight on the platform is displayed. Press the A.R. key to switch to high
resolution for 5 seconds. Cyclical transmission of the string containing the weight in
high resolution is enabled on com2 with protocol 9600 8-N-1.
Converter
Test
Connect optional accessory card
404031 to run test 0..20000div.
