ADVANCED USE MANUAL DD700
Start (*)(***)
In extraction mode (see Using the terminal chapter in the user manual) this runs
the START operation by supplying Output1 (Requested) and Output 2 (Slow)
output contacts.
The same operation can be executed by pressing START on the terminal display.
The following START operation is accepted when the value set in Set Point 01 is
reached or after a STOP request.
Stop (*)(***)In extraction mode (see Using the terminal chapter in the user
manual) this forces the cycle to end by deactivating Output1 (Requested) and
Output 2 (Slow) output contacts.
The same operation can be executed by pressing STOP on the terminal display.
3.6.18 Setup Menu/Customisation/Outputs/Analogue Outputs(OPTIONAL)
Gross, Net, Hi.Res.Gross, Hi.Res. Net( Hi.Res.= High Resolution). Gross / Net
return receipt They are present only with new board), reference weight (“*”,”***”).
0-10 V voltage
0-20 mA current
4-20 mA current
3.6.19 Setup Menu/Customisation/Messages
If a printer is connected, it is possible to print the current message configuration.
A list will be printed out, much like the one illustrated in the dedicated paragraph.
The number, the original message and any editing to it, will be printed.
It is possible to edit the messages that are presented to the operator during
normal operation, so that they can be adapted to any specific requirements.
Proceed as follows:
enter the code for the message that requires editing, retrieving it from the
provided list or from the printout of any messages executed by the terminal;
press ;
enter the new description using the alphanumerical keyboard as explained in
the Using the terminal chapter in the user manual.
press ;
press
ESC
several times until you return to normal weight display mode.
It is possible to reset any edited messages. Reset messages is only included in
the menu if there are any edited messages in the memory.
