ADVANCED USE MANUAL DD700
3.6.16 Setup Menu / Customisation / Outputs / Serial / String /.../ Com xy
configuration
Once you have selected the type of string you will access the Configuration menu for the hardware
characteristics of the serial output, which contains the following parameters:
Baud rate
600, 1200, 2400, 4800, 9600, 19200, 38400, 57600, 115200
serial line transmission speed
Number of bits
7, 8
Number of stop
bits
1, 2
Parity
Even, Odd, None
Communication
interface
RS232, RS422, RS485
Serial com
control
Hardware, Software, None
Hardware: CTS and RTS signals are used. The input CTS signal must be placed
on +12V to enable transmission on the TX foot. The terminal places the output
RTS signal on +12V to report its availability to receive (only available on COM1).
Software: sending the character
<XON>(11H)
enable transmission;
<XOFF>(13H)
suspend transmission;
