ADVANCED USE MANUAL DD700
3.6.17 Setup Menu/Customisation/Outputs/Input-Output
operation
(output)
Disab. (disabled)
Set point
Range
Requested(*)(***)
Slow(*)(***)
Piece setpoint (**)
Piece range (**)
Print ok
Transmiss. ok (transmission ok)
Error Digital cells
Weight in tolerance (**)
Managed in Checkweight mode (see Using the terminal chapter in the user
manual) or in Operation: Standard, Sum, or Multi Operator if "SELECT" display is
selected.
Weight below tolerance (**)
Managed in Checkweight mode (see Using the terminal chapter in the user
manual) or in Operation: Standard, Sum, or Multi Operator if "SELECT" display is
selected.
Weight above tolerance (OPTIONAL)
Managed in Checkweight mode (see Using the terminal chapter in the user
manual) or in Operation: Standard, Sum, or Multi Operator if "SELECT" display is
selected.
Green (*)(***)
It must be set for signal light management
Red (*)(***)
It must be set for signal light management
resting status
Norm. open (normally open)
Norm. closed (normally closed)
operation
(input)
Disab. (disabled)
Zeroset scale
Acquire tare
Delete tare
Acq./Del. tare (acquire/delete tare)
Print weight
Disab. weighing operation (Disable weighing operation)
