• Month of the real time clock (Month)
Enter the month (1 up to 12).
• Day of the real time clock (Day)
Enter the day (1 up to 31).
• Time of the real time clock (Time)
Main menu. Use the program key to access the settings of hour and minute in the corresponding
submenus.
There is no automatic switch between daylight saving time and regular time.
• Hour of the real time clock (Hour)
Enter the hour (0 up to 23).
• Minute of the real time clock (Minute)
Enter the minute (0 up to 59).
Normal Display
Display 1 shows e.g. 39.8
C
(actual temperature value)
Display 2 shows
e.g. 15.05.06 13:52 - -
(actual date and time, actual switching state of week
program timer channel 1: Off, channel 2: Off)
Press down key
for 5 sec
Display 1 shows e.g. 0000
Display 2 shows PROGRAM EDITOR (you are in the program editor)
Press down key
for 5 sec
Display 1 shows 0000 Menu visible only if week program timer is activated.
Display 2 shows WEEK PROG. EDITOR (you are in the week program editor)
Press down key
for 5 sec
Display 1 shows 0000
Display 2 shows USER – LEVEL (you are in the user level)
Press program key
Display 1 shows 0000
Display 2 shows UserCod? 0000 (enter user code, display flashes)
Enter the user code using arrow keys
e.g. 0001 (basic setting,
or the valid code in case it has been previously
changed in this menu).
Value is shown in both displays.
Automatically forward after 2 sec
Display 1 shows 1 (actual address: 1)
Display 2 shows
Adress 1
(entry of unit address)
(actual address: 1)
Enter the unit address (1 up to 254) using
arrow keys
Address is shown in both displays.
Press key
To Next Page
