Display 1 shows 1 (actually valid user code: 1)
Display 2 shows
User-cod 1
(change user code)
(actually set: 1)
Enter a new value using arrow keys Value is shown in both displays.
Press key
Display 1 shows 0000 (no function)
Display 2 shows Saf.mode: Limit (no function)
Press key
Display 1 shows 0 (no function)
Display 2 shows Saf.setp 0 (no function)
Press key
Display 1 shows 0000 (no function)
Display 2 shows
Decimal: XXX.X
(setting of decimal point position)
(actual setting: XXX.X)
Select decimal point position using arrow
keys
Decimal point position XXX.X or XXXX. is
shown in display 2.
Press key
Display 1 shows 0000 (no function)
Display 2 shows
Buzzer : Active
(setting of the alarm buzzer)
(actual setting: „Active“)
Select between “Active” and “Inactiv” using
arrow keys
Setting is shown in display 2.
Press key
Display 1 shows 0000 (no function)
Display 2 shows
Language : English
(selection of controller language)
(actual setting: English)
Select between languages German, English,
and French using arrow keys
Setting is shown in display 2.
Press key
Display 1 shows e.g. 0004 (unit operating hours)
Display 2 shows
Oper.hs 0004:28
(operating hours up to now hhhh:mm)
(actually displayed: 4 hs 28 min)
Press key
Display 1 shows 1000 (actual setting: 1000 hs)
Display 2 shows
Op.limit
1000:00 (maximum number of operating hours
hhhh:mm (actual setting: 1000 hs)
Set value using arrow keys Setting is shown in both displays.
Press key
Display 1 shows 0000 (no function)
Display 2 shows
Op.back : No
(reset counter of operating hours ?)
(actual setting: No)
Select between “Yes” and “No” using arrow
keys
Setting is shown in display 2.
