Select between “Active” and “Inactive” using
arrow keys
Setting is shown in display 2.
Press key
Display 1 shows 0000
Display 2 shows
12h/24h 24h
(Display mode 12 hours or 24 hours?
(actual setting: 24h)
Select between 12 hours and 24 hours
using arrow keys
Setting is shown in display 2.
Press key
Display 1 shows 0000
Display 2 shows Date (Main menu: Setting the date of the real time clock)
Press program key
Display 1 shows e.g. 2006 (Actual setting: 2006)
Display 2 shows Year 2006 (Setting the year of the real time clock)
Set year (2006 up to 2050) using arrow keys Setting is shown in display 2.
Press key
Display 1 shows e.g. 5 (Actual setting: may)
Display 2 shows Month 5 (Setting the month of the real time clock)
Set month (1 up to 12) using arrow keys Setting is shown in display 2.
Press key
Display 1 shows e.g. 15 (Actual setting: 15)
Display 2 shows Day 15 (Setting the day of the real time clock)
Set day (1 up to 31) using arrow keys Setting is shown in display 2.
Press key
EXIT
Press key
Display 1 shows 0000
Display 2 shows Time (Main menu: Setting the time of the real time clock)
Press program key
Display 1 shows e.g. 13 (Actual setting: 13, i.e. 1 p.m.)
Display 2 shows Hour 13 (Setting the hour of the real time clock)
Set hour (0 up to 23) using arrow keys Setting is shown in display 2.
Press key
Display 1 shows e.g. 30 (Actual setting: 30 minutes)
Display 2 shows Minute 30 (Setting the minute of the real time clock)
Set minute(0 up to 59) using arrow keys Setting is shown in display 2.
Press several times key
EXIT
or wait for 120 seconds
Controller returns to normal display.
