KBF / KBF-UL + KMF (E6) 09/2021 page 12/160
1.6 Type plate
The type plate sticks to the left side of the chamber, bottom right-hand.
Figure 3: Type plate (example KBF 240 regular chamber 9020-0322)
Indications of the type plate (example)
Indication
Information
BINDER
Manufacturer: BINDER GmbH
KBF 240
Model designation
Constant climate chamber
Device name
Serial No.
00000000000000
Serial no. of the chamber
Built
2021
Year of construction
Nominal temperature
70 °C / 158 °F
Nominal temperature
IP protection
20
IP type of protection acc. to standard EN 60529
Temp. safety device DIN 12880
Temperature safety device acc. to standard DIN
12880:2007
Class
3.1
Class of temperature safety device
Art. No.
9020-0322
Art. no. of the chamber
Project No.
---
Optional: Special application acc. to project no.
2,10 kW
Nominal power
9,5 A
Nominal current
200-230 V / 50 Hz
Nominal voltage range +/-10%
at the indicated power frequency
200-230 V / 60 Hz
1 N ~
Current type
Max. operating pressure 15 bar
Max operating pressure in the refrigerating system
(15 bar / 218 PSI)
R 134A - 0,17 kg
Refrigerant type and filling weight
Contains fluorinated greenhouse gases covered by the Kyoto Protocol
Symbols on the type plate
Symbol Valid for Information
All chambers CE conformity marking
All chambers
Electrical and electronic equipment manufactured / placed on
the market in the EU after 13 August 2005 and be disposed
of in separate collection according to Directive 2012/19/EU
on waste electrical and electronic equipment (WEEE).
Nominal temp.
70 °C
2,10 kW / 9,5 A
Max. operating pressure 15 bar
158 °F
200-230 V / 50 Hz
R 134A – 0,17 kg
IP protection
20
200-230 V / 60 Hz
Contains fluorinated
Safety device
DIN 12880
1 N ~
greenhouse gases covered
Class
3.1
by the Kyoto Protocol
Art. No.
9020-0322
Project No.
Built
2021
Constant climate chamber
BINDER GmbH
Im Mittleren Ösch 5
78532 Tuttlingen / Germany
www.binder-world.com
KBF 240
E6
Serial No. 00000000000000
Made in Germany
