KBF / KBF-UL + KMF (E6) 09/2021 page 34/160
4.4 Electrical connection
The chambers are supplied ready for connection. They come with a fixed power connection cable of at
least 1800 mm / 70.87 in in length.
Model version
Art. No.
(x = 0 or 1)
Power plug
Voltage +/-10% at the
indicated power fre-
quency
Current
type
Chamber
fuse
KBF115-230V
KBF240-230V
KBF720-230V
KBF1020-230V
9x20-0320
9x20-0322
9x20-0324
9x20-0326
Grounded plug
200-230 V at 50 Hz
200-230 V at 60 Hz
1N~ 16 Amp
KBF115UL-240V
KBF240UL-240V
KBF720UL-240V
KBF 1020UL-240V
9x20-0321
9x20-0323
9x20-0325
9x20-0327
NEMA 6-20P
200-240 V at 50Hz
200-240 V at 60Hz
2~ 16 Amp
KMF115-230V
KMF240-230V
KMF720-230V
9x20-0341
9x20-0343
9x20-0345
Grounded plug
200-230 V at 50 Hz
200-230 V at 60 Hz
1N~ 16 Amp
KMF115-240V
KMF240-240V
KMF720-240V
9x20-0342
9x20-0344
9x20-0346
NEMA 6-20P
200-240 V at 50Hz
200-240 V at 60Hz
2~ 16 Amp
• The domestic socket must also provide a protective conductor. Make sure that the connection of the
protective conductor of the domestic installations to the chamber’s protective conductor meets the latest
technology. The protective conductors of the socket and plug must be compatible!
DANGER
Electrical hazard due to missing protective conductor connection.
Deadly electric shock.
 Make sure that the chamber’s power plug and the power socket match and se-
curely connect the electrical protective conductors of the chamber and the house
installation.
• Only use original connection cables from BINDER according to the above specification.
UL chambers: Use only a UL Listed Power supply cord (UL category ELBZ), SJT 3x14 AWG (2.08 mm²);
C13L. For outside USA use a certified power supply cord according to national requirements.
• Prior to connection and start-up, check the power supply voltage. Compare the values to the specified
data located on the chamber’s type plate (left chamber side, bottom right-hand, see chap. 1.6).
NOTICE
Danger of incorrect power supply voltage due to improper connection.
Damage to the chamber.
 Check the power supply voltage before connection and start-up.
 Compare the power supply voltage with the data indicated on the type plate.
• When connecting, please observe the regulations specified by the local electricity supply company as
well as the local or national electrical regulations (VDE directives for Germany).
• Observe a sufficient current protection according to the number of devices that you want to operate. We
recommend the use of a residual current circuit breaker.
• Pollution degree (acc. to IEC 61010-1): 2
• Installation category (acc. to IEC 61010-1): II
See also electrical data (chap. 23.5).
