Binder KBF 1020 - Mounting the Freshwater Can

KBF / KBF-UL + KMF (E6) 09/2021 page 122/160
19.7.1 Mounting the freshwater can
(1) Fixing (if required)
Hang the can with its holding device on its 4 carriers. You can install it either at the left or the right
side.
Cable connection (15)
Freshwater hose connection (16)
Figure 23: Freshwater can (option)
(2) Cable connections
Connect the plug of the cable to the socket (10) at the rear of the chamber.
The socket (10) is marked with a sticker:
Socket (10) (14)
(13)
Figure 24: Connections at the chamber rear
