2.4 Rear view with water connections
(10)
(11)
(13) (14)
Figure 7: Rear view of the chamber with water connections
(10) Socket for optional freshwater can (chap. 19.9.1)
(11) Power cable
(12) not used
(13) Freshwater connection “IN” with screw thread ¾’’ for hose ½“, with union nut
(14) Wastewater connection “OUT” with hose olive for hose ½“
