2.1 Chamber overview
Figure 3: VD 23 with option vacuum module and chemical membrane pump
(A) Control panel and instrument box
(B) Chamber door
(C) Elastic-mounted safety glass window
(D) Vacuum module (option)
(E) Chemical membrane pump (option)
(A)
(B)
(C)
(D)
(E)
