VD (E2.1) 07/2017 page 77/96
All technical data is specified for unloaded chambers with standard equipment (with aluminum racks) at
an ambient temperature of +22 °C ± 3 °C / 71.6 °F ± 5.4 °F and a power supply voltage fluctuation of ±10.
Technical data is determined in accordance to BINDER Factory Standard Part 1:2015 following DIN
12880:2007.
All indications are average values, typical for chambers produced in series. We reserve the right
to change technical specifications at any time.
20.3 Equipment and options (extract)
To operate the chamber, use only original BINDER accessories or accessories / components
from third-party suppliers authorized by BINDER. The user is responsible for any risk arising
from using unauthorized accessories.
Regular equipment
Microprocessor program controller RD3 with LED display
Safety device class 2 according to DIN 12880:2007
RS 422 printer and communication interface with adjustable printing intervals
Fine-dosing aeration valve
Inert gas connection with fine-dosing valve
Analog pressure display (manometer) (not with option digital pressure display)
Measuring connection (DN 16), rear
Safety glass panel
2 switching contacts 24V DC via operation lines
Intelligent adaptation of the heating power by soft heating-up function (selectable on-off)
Options / accessories
Expansion racks, aluminum or stainless steel 1.4571
FKM door gasket (temperature resistant up to 200 °C / 392 °F)
Additional measuring channel for digital object temperature display with flexible Pt 100 temperature
sensor
Digital pressure display (adjustable)
Communication software APT-COM™ for logging and display of temperature data and networking up to
30 chambers with PC
Protocol printer for numeric and graphic temperature documentation (available via BINDER INDIVIDUAL
customized solutions)
2-channel pen recorder, external (available via BINDER INDIVIDUAL customized solutions)
Connection kit VD with various small flange parts
Measuring access port vacuum 9 poles
Vacuum module empty (without pump)
Vacuum module with chemical membrane pump VP 1.1 (MZ2C) with separator and emission condenser,
ready for connection
•
Ready to connect: Suction power
m
3
/h
2.0
•
End vacuum
mbar / inHg
7 / 0.21
•
Electrical connection (50-60 Hz)
V
115 / 230
Vacuum module with chemical membrane pump VP 2.1 (MD4C) with separator and emission condenser,
ready for connection
•
Ready to connect: Suction power
m
3
/h 3.4
•
End vacuum
mbar / inHg
1.5 / 0.04
•
Electrical connection (50-60 Hz)
V
115 / 230
