20. Technical description
20.1 Factory calibration and adjustment
This chamber was calibrated and adjusted in the factory. Calibration and adjustment were performed
using standardized test instructions, according to the QM DIN EN ISO 9001 system applied by BINDER
(certified since December 1996 by TÜV CERT). All test equipment used is subject to the administration of
measurement and test equipment that is also a constituent part of the BINDER QM DIN EN ISO 9001
systems. They are controlled and calibrated to a DKD-Standard at regular intervals.
Factory adjustment was done in the center of the usable volume and under vacuum conditions. the
sensor is fixed in the middle of the expansion rack in a way ensuring good thermal conductivity (heat
conduction). Measuring is performed in equilibrated state.
CAUTION
Invalid calibration.
∅ Do NOT change between aluminum and stainless steel racks.
 Use the delivered expansion racks only.
20.2 Technical data
Chamber size
23
53
115
External dimensions
Vacuum oven
Width, net
mm / inch
515 / 20.28
634 / 24.96
740 / 29.13
Height, gross (including feet)
mm / inch
655 / 25.79
775 / 30.51
900 / 35.43
Depth, net
mm / inch
500 / 19.69
550 / 21.65
670 / 26.38
Depth, gross (including door handle,
connections)
mm / inch 600 / 23.62 650 / 25.59 770 / 30.31
Vacuum module (option)
Width, net
mm / inch
515 / 20.28
634 / 24.96
740 / 29.13
Height, net
mm / inch
624 / 24.57
624 / 24.57
622 / 24.49
Depth, net
mm / inch
500 / 19.69
550 / 21.65
670 / 26.38
Depth, gross (including door handle,
connections)
mm / inch 600 / 23.62 650 / 25.59 770 / 30.31
Chamber with optional vacuum module
Width, net
mm / inch
515 / 20.28
634 / 24.96
740 / 29.13
Height, net
mm / inch
1279 / 50.35
1400 / 55.12
1522 / 59.92
Depth, net
mm / inch
500 / 19.69
550 / 21.65
670 / 26.38
Depth, gross (including door handle,
connections)
mm / inch 600 / 23.62 650 / 25.59 770 / 30.31
Wall clearances
Wall clearance, rear (minimum)
mm / inch
100 / 3.94
100 / 3.94
100 / 3.94
Wall clearance, side (minimum)
mm / inch
135 / 5.31
135 / 5.31
135 / 5.31
Internal dimensions
Width
mm / inch
285 / 11.22
400 / 15.75
506 / 19.92
Height
mm / inch
285 / 11.22
400 / 15.75
506 / 19.92
Depth
mm / inch
295 / 11.61
340 / 13.38
460 / 18.11
Interior volume
l / cu.ft.
23 / 0.8
53 / 1.9
115 / 4.1
