VD (E2.1) 07/2017 page 74/96
temperature set-point in
Invalid calibration
Use the delivered expansion racks
only. Do NOT change between
aluminum and stainless steel racks
Wrong temperature value
measured during calibration.
Reference temperature sensor
has insufficient contact to
Fix the reference temperature
sensor with thermal conductive
paste or adhesive aluminum tape.
Leakage current when using a
thermo element not electrically
Mount a thermo element electrically
isolated from the rack.
Vacuum not held.
Safety glass panel defective.
Replace safety glass panel.
connections (universal eccentric
Replace gaskets of small flange
connections.
Inner tube connection leaky.
Program duration longer than
programmed.
Inappropriate tolerances have
been programmed.
For rapid transition phases, do
NOT program tolerance limits in
order to permit maximum heating
Program stops one section too
early.
Program line is incomplete.
When programming, define the end
value of the desired cycle by
adding an additional section with a
section time of at least one minute
Programs have been deleted.
Change from 2 programs to 1
program or vice-versa
When changing, ensure that the
programs are no longer needed.
The controller returns to Normal
Display from any level.
No button was pressed for more
than 120 sec.
Repeat entries, enter the values
rapidly.
Message RANGE ERROR CH1
in Normal Display in Display 2
Sensor rupture between sensor
and controller
Contact BINDER Service.
Ramp temperature transitions
are only realized as steps.
Set-point programming type set
to “Step” in the User level (chap.
Set the set-point programming type
to setting “Ramp” in the User level
Only qualified service personnel authorized by BINDER must perform repair.
Repaired chambers must comply with the BINDER quality standards.
