VD (E2.1) 07/2017 page 65/96
16.8 Communication software APT-COM™ 3 DataControlSystem (option)
The chamber is regularly equipped with a serial interface RS 422 (9) that can connect the BINDER
communication software APT-COM™ 3 DataControlSystem. The actual temperature value is given at
adjustable intervals. Programming can be performed graphically via PC. Up to 30 chambers with RS 422
interface can be cross-linked. For further information, refer to the operating manual of the BINDER
communication software APT-COM™ 3.
Confirm that the interface mode is correctly set to “Modbus” in the user level (chap. 10).
Pin allocation of the RS 422 interface (9):
pin 3: TxD (+)
pin 4: RxD (-)
pin 5: TxD (-)
17. Maintenance, cleaning, and service
17.1 Maintenance intervals, service
DANGER
Electrical hazard.
Danger of death.
∅ The chamber must NOT become wet during operation or maintenance work.
∅ Do NOT remove the rear panel of the chamber.
Before conducting maintenance work, turn off the chamber
and disconnect the power plug.
Ensure all maintenance work is conducted by licensed electricians
authorized by BINDER.
Ensure regular maintenance work is performed at least once a year.
The warranty becomes void if maintenance work is conducted by non-authorized personnel.
Replace the door gasket only when cold. Otherwise, the door gasket may become damaged.
We recommend taking out a maintenance agreement. Please consult BINDER Service.
BINDER telephone hotline: +49 (0) 7462 2005 555
BINDER fax hotline: +49 (0) 7462 2005 93555
BINDER e-mail hotline: service@binder-world.com
BINDER service hotline USA: +1 866 885 9794 or +1 631 224 4340 x3 (toll-free in the USA)
BINDER service hotline Asia Pacific: +852 390 705 04 or +852 390 705 03
BINDER service hotline Russia and CIS +7 495 988 15 16
BINDER Internet website http://www.binder-world.com
BINDER address BINDER GmbH, post office box 102, D-78502 Tuttlingen
International customers, please contact your local BINDER distributor.
