Binder VD 53 - Proceeding in Detail

VD (E2.1) 07/2017 page 29/96
7.2.3 Proceeding in detail
1. Settings in the user level
• Activating the week program timer
• Checking and, if necessary, setting the real time clock
Normal Display
Display 1 shows
e.g. 39.8
C
(actual temperature value)
Display 2 shows
e.g. 15.05.06 13:52 - -
(actual date and time, actual switching state of week
program timer channel 1: Off, channel 2: Off)
Press down key
for 5 sec
Display 1 shows
e.g. 0000
Display 2 shows
PROGRAM EDITOR
(you are in the program editor)
Press down key
for 5 sec
Display 1 shows
0000
Menu visible only if week program timer is activated.
Display 2 shows
WEEK PROG. EDITOR
(you are in the week program editor)
Press down key
for 5 sec
Display 1 shows
0000
Display 2 shows
USER – LEVEL
(you are in the user level)
Press program key
Display 1 shows
0000
Display 2 shows
UserCod?
0000
(enter user code, display flashes)
Enter the user code using arrow keys
e.g. 0001 (basic setting, or the valid code in
case it has been previously changed in this
menu).
Value is shown in both displays.
Automatically forward after 2 sec
Display 1 shows
1
(actual address)
Display 2 shows Adress 1
(entry of chamber address)
(actual address: 1)
Press several times key
until Prog.Clk appears:
Display 1 shows
0000
Display 2 shows Prog.Clk Inactive
(Week program timer active or inactive?
(actual setting: Inactive)
Select “Active” using arrow keys
Setting is shown in display 2.
Press key
Display 1 shows
0000
Display 2 shows 12h/24h 24h
(Display mode 12 hours or 24 hours?
(actual setting: 24h)
Press key
Display 1 shows
0000
Display 2 shows
Date
(Main menu: Setting the date of the real time clock)
Press program key
