Chapter1 Motherboard Description
1-16
1.6 Connectors, Headers & Jumpers
The connectors, headers and jumpers introduced below provide you lots of
capabilities such as power supply, front panel signal revelation, IDE hard disk
connection, floppy disk connection, Wake On LAN function and Front USB
connection. Noticeably, a jumper has two or more pins that can be covered by a
plastic jumper cap, allowing you to select different system options.
JWOL1
1
1
1
JUSB2
JPANEL1
JUSB2
JCMOS1
RAID
RAID2
RAID1
FDD1
IDE2
IDE1
JDIMMPWR1
JATXPWR1
To Next Page
