Chapter1 Motherboard Description
1-24
1.7.3
Serial and Parallel Interface Ports
This system comes equipped with two serial ports and one parallel port. Both types
of interface ports will be explained in this chapter.
1.7.3.1 The Serial Interface: JCOM1/JCOM2
The serial interface port is sometimes referred to as an RS-232 port or an
asynchronous communications port. Mice, printers, modems and other peripheral
devices can be connected to a serial port. The serial port can also be used to
connect your computer with another computer system. If you wish to transfer the
contents of your hard disk to another system it can be accomplished by using each
machine’s serial port.
The serial ports on this system have two 9-pin connector. Some older computer
systems and peripherals used to be equipped with only one 25-pin connector.
Should you need to connect your 9-pin serial port to an older 25-pin serial port,
you can purchase a 9-to-25 pin adapter.
