Chapter1 Motherboard Description
1-22
1.7 Back Panel Connectors
Rear Speaker out
This driver will also work for two channel systems. You can play DVD movies
using InterVideo’s Win DVD software, if using four channel systems.
1.7.1 PS/2 Mouse / Keyboard Connectors: JKBMS1
The motherboard provides a standard PS/2 mouse / Keyboard mini DIN connector
for attaching a PS/2 mouse. You can plug a PS/2 mouse / Keyboard directly into
this connector. The connector location and pin definition are shown below:
PS/2
Keyboard
PS/2
Mouse
USB
COM1
Parallel
Game Port
Front
Speaker
Out
Line In
/Rear
Speaker
Out
Mic
In
JPRNT1
JGAME1
COM2COM1
COM2
JKBMS1
JUSB1 JSPKR1 JLIN1 JMIC1
