Biostar M6TSU User Manual

Chapter1 Motherboard Description
1-19
1.6.2 ATX 20-pin Power Connector: JATXPWR1
This connector supports the power button on-board. Using the ATX power
supply, functions such as Modem Ring Wake-Up and Soft Power Off are
supported on this motherboard. This power connector supports instant power-on
functionality, which means that the system will boot up instantly when the power
connector is inserted on the board.
PIN Assignment PIN Assignment
1
3.3 V
11
3.3 V
2
3.3 V
12
-12 V
3
Ground
13
Ground
4
5 V
14
PS_ON
5
Ground
15
Ground
6
5 V
16
Ground
7
Ground
17
Ground
8
PW_OK
18
-5 V (Optional)
9
5V_SB
19
5 V
10
12 V
20
5 V
1.6.3 DIMM Power Header: JDIMMPWR1
PIN Assignment
1-2
3.3 V
3-4 3.4 V
5-6
3.5 V
7-8
3.6 V
