Chapter1 Motherboard Description
1-28
1.7.6 Audio Subsystem
1.7.6.1 AUX Audio in Header: JAUX1 (Optional)
Pin No. Assignment
1
Left Channel Aux-in
2 Ground
3
Ground
4
Right Channel Aux in
JAUDIO1
JAUX1
JTAD1
JCDIN1
JCDIN2
1
1
1
1
1
