Chapter1 Motherboard Description
1-2
1 Motherboard Description
1.1 Features
1.1.1 Hardware
CPU
− The Pentium
®
!!!
processors (FC-PGA) and Celeron
TM
(FC-PGA)
processor (533MHz and > 566MHz) and Tualatin (FC-PGA2)
processor the new generation power for high-end workstations and
servers.
− Provides Socket 370.
− Running at 66 MHz,100 MHz and 133MHz Front Side Bus frequency.
Speed
− Supports from 533 MHz to 1.2 GHz CPU core speeds.
− Supports 33MHz PCI Bus speed.
DRAM Memory
− Provides three DIMM module sockets.
− Supports 3.3V unbuffered 168pin Synchronous DRAM modules.
− Supports a maximum memory size of 512 MB with SDRAM.
− 100/133MHz Bus frequency.
− Supports up to 3 double sided DIMMs at 100 MHz system memory
bus.
− Supports up to 2 double sided or 3 single sided DIMMs at 133 MHz
system memory bus.
− No registered DIMM supported.
− No ECC SDRAM supported.
Shadow RAM
− Supports shadowing of system BIOS into RAM for faster performance.
Green PC Power Management Functionality
− BIOS supported power management.
− Power down timer from 1 min to 1 Hour.
