Chapter1 Motherboard Description
1-3
− Wakes up by any key pressed or mouse activity.
− Wake On LAN connector.
− S3 (suspend to RAM) support.
BUS Slots
− Provides six PCI Bus slots, one CNR slot (slave only) and one AGP
Bus slot.
Integrated IDE controller
− Supports 4 IDE hard disk drives.
− Supports PIO mode 5, Master Mode high performace hard disk drives.
− Supprots Ultra DMA 33/ 66/ 100 Bus Master Mode.
− Supports IDE interface with CD-ROM.
− Supports high capacity hard disk drives.
− Supports LBA mode.
− Driver detected by BIOS.
Accelerated Graphics Port (AGP)
− Supports AGP 2.0 including 4X AGP data transfers.
− High priority access support.
− Hierarchical PCI configuration mechanism.
− Supports via dual mode buffers to allow AGP 2.0, 3.3V or 1.5V
signaling.
AC’97 Sound Codec Onboard
− AC-LINK protocol compliance.
− AC’97 2.1 compliant.
− Single chip audio CODEC with high S/N ratio (>90 dB)
− 18-bit ADC and DAC resolution.
− 18-bit stereo full-duplex CODEC with independent and variable
sampling rate.
LPC I/O Built-in Onboard
− LPC Interface.
− PC98, PC99 Compliant.
− Game Port Interface.
