Chapter1 Motherboard Description
1-4
− MPU-401 MDI Support.
− Intelligent Auto Power Management.
− 2.88MB Super I/O Floppy Disk Controller.
− Floppy Disk Available on Parallel Port Pins.
Supports 360KB, 720KB, 1.2MB, 1.44MB, and 2.88MB floppy
disk drives.
− Enhanced Digital Data Separator.
− Serial Ports.
Two full Function Serial Ports.
Supports 230K and 460K Baud Programmable Baud Rate
Generator Modem Control Circuitry.
− Infrared Port.
− Multi-Mode™ Parallel Port with ChipProtect™.
HPT370 is designed to enable you add high performance
ATA/ATAPI devices. (Optional)
− Ultra DMA 100MB/S operation per ATA channel.
− Support up to 66MHz PCI bus Clock.
− One PCI function supports two independent ATA channels.
− Dedicated ATA Bus.
− ATA clock independent from PCI bus.
− Optional between external 50Hz ATA bus clock or internal PLL.
− 256Byte FIFO per ATA channel.
− Large FIFO independent.
− Easy Plug-and-Play feature.
− Supports up to 4 IDE devices. (Coexist with on-board IDE)
− Supports Hard Drive with capacity larger than 30GB.
− RAID function supported (RAID 0,1,0+1).
− Supports the most popular Windows 95/98,Windows NT4.0, Windows
2000, Windows ME and Linux.
− Supports booting function with Flash Memory interface.
− Automatically fine tunes to the best performance for each IDE/ATAPI
device.
− Concurrent PIO and bus master access(ATA port accessible during
DMA transfer)
