Chapter 2 BIOS Setup
2-17
The Choices: Half (default), Full.
Use IR Pins
Consult your IR peripheral documentation to select the correct setting of the TxD
and RxD signals.
The Choices: IR-Rx2Tx2 (default), RxD2 TxD2.
Onboard Parallel Port
This item allows you to determine access onboard parallel port controller with
which I/O Address.
The Choices: 378/IRQ7 (default), 278/IRQ5, 3BC/IRQ7, Disabled.
Parallel Port Mode
The default value is SPP.
SPP (default) Using Parallel Port as Standard
Printer Port.
EPP Using Parallel Port as Enhanced
Parallel Port.
ECP Using Parallel Port as Extended
Capabilities Port.
ECP+EPP Using Parallel Port as ECP & EPP mode.
Normal Supports EPP or ECP mode.
EPP Mode Select
Select EPP port type 1.7 or 1.9.
The Choices: EPP1.7 (default), EPP1.9.
ECP Mode Use DMA
Select a DMA Channel for the port.
The Choices: 3 (default), 1.
