Biotech TLM-Pro - PZ 45;50;55 RL Dimensions

16
4
3
1) with mounted ash discharge 1200 mm
2) recommendation 250 mm, otherwise
increased maintenance eort (costs)
Minimum distance masonry
1 : 900 mm
1
3 : 100-300 mm
2
2 : 400-900 mm 4 : 500-900 mm
PZ 50PZ 50
1744
1944
40
190
1235
1450
1505
150
140
80 817 385
70 70
485
485
PZ 45/50/55 RL
Pellet boiler
Insert dimensions
boiler (min.)
A: 800 mm
B: 1800 mm
C: 800 mm
Insert dimensions
container (min.)
A: 840 mm
B: 1950 mm
C: 820 mm
Boiler 324 kg
Container 84 kg
Cladding 95 kg
Ash box 15 kg
All 503 kg
KG
A
B
C
MINIMUM DISTANCE
MASONRY
1: 1200 mm
2: 600-900 mm
3: 700-900 mm
4: 700-900 mm
5: 2300 mm
PLANING FOLDER PELLET BOILER
5.7 PZ 45/50/55 RL
