Individual values are based on the standard type test. These may deviate in practice.
*) Combined label (boiler+room thermostat)
1) excl. adjustable feet, adjustment range up to 55 kW 15–30 mm and from 65-101 kW 50-80 mm
2) From 10 Pa, a draught limiter must be used below the firing connection
3) Recommendation at least 250 mm, otherwise increased maintenance eort (costs)
4) with 1 suction turbine
5) incl. ashbox
6) incl. cover for cleaning
Boiler typeBoiler type PZ 32/35 Pro MBWPZ 32/35 Pro MBW PZ 45/50/55 RLPZ 45/50/55 RL PZ 65/69/80 RLPZ 65/69/80 RL PZ 90/100 RL PZ 90/100 RL
44
PZ 100/101 RLPZ 100/101 RL
Boiler class 5 5 5 5 5
Nominal heat output (kW) 32,2 / 34,9 44,9/ 49,0 / 52,8 64,9 / 69,0 / 80,0
90,0 / 99,9 99,9 / 101,0
Eciency full load (%) 92,39 93,7 93,4 94,8 94,8
Eciency part load (%) 95,76 93,0 94,6 95,3 95,3
Max. adjustable boiler temperature (C°) 90 85 85 85 85
Permissible operating pressure (bar) 3 3 3 3 3
Recommended minimum storage volume (l) 966 / 1047 1347 / 1470 / 1584 1947 / 2070 / 2400 2700 / 2997 2700 / 2997
CE marking according to Low Voltage Directive CE CE CE CE CE
Energy eciency class A+ A++* A++* - -
Dimensons
Boiler width (mm) 1305 1505 1744
5
1745
5
1745
5
Boiler depth (mm) 945 817 1221 1221 1221
Total depth (mm) 1158
5
1202
5
1339
6
1339
6
1339
6
Boiler height (mm)
1
1694 1944 1820 2068 2068
Height flue pipe connection (mm)
1
1605 1235 1769 2020 2020
Height forerun (mm)
1
353 190 176 176 176
Height return (mm)
1
1324 1450 1246 1491 1491
Vent height (mm)
1
1341 1453 1333 1578 1578
Flue pipe connection diameter (mm) 130 130 180 200 200
Total weight loose (kg) 426 503 920 / 920 / 930 1153 1160
Water content (l) 120 180 248 273 273
Reservoir - filling quantity (kg) 246 210 152 323 323
Ash box usable (l) 15 42 2x42 2x42 2x42
Connections
Forerun (Inch) 1 ⁄ 1 ⁄ 2 2 2
Return (Inch) 1 ⁄ 1 ⁄ 2 2 2
Ventilation for boiler (Inch) ⁄ ⁄ 1 1 1
Boiler draining (Inch) ⁄ ⁄ ⁄ ⁄ 1/2
Flow resistance on the heating water sideFlow resistance on the heating water side
ΔT= 20 K (mbar) 103 4 5 5 5
ΔT= 10 K (mbar) 412 16,3 20 20 20
Exhaust gas values
Exhaust gas temperature at full load (C°) 120 120 120 120 120
Exhaust gas temperature at part load (C°) 100
100 100 100 100
Exhaust gas mass flow at full load (g/s) 22,0
32 41 52 52
Exhaust gas mass flow at part load (g/s) 5,8
12,3 10,5 13 13
Co
2
at full load (Vol%) 13,5 13,5 13,5 13,5 13,5
Co
2
at part load (Vol%) 10,0 10,0 10,0 10,0 10,0
Necessary flue draught full load (Pa)  8 8 8 8 8
Necessary flue draught part load (Pa) 4 4 4 4 4
Electrical power consumption
Standby (W) 20 20 14 14 14
Filling turbine (W) 0 1340 1340 2720 2720
Grate cleaning (W) 65 65 65 65 65
Prefill (W) 75 75 75 75 75
Ignite (W) 1034 1034 1034 1034 1034
Continuous operation Partial load / Full load (W) 50 / 80 52,6 / 101,4 97 / 153 111 / 200 111 / 200
Minimum distance masonry
To the front (mm) 1000 1200 500 500 500
To the back (mm) 500-900 700-900 700 700 700
Left to masonry (mm) 100-300
3
700-900 1200 1200 1200
Right to masonry (mm) 400-900 600-900 750 750 750
Minimum room heigh (mm) 2200 2300 2300 2500 2500
Insert dimension
At least (mm) 750 875 1000 1000 1000
