Operating instructions VS12D /C /-R /-V /-
V/R
Maintenance
6.083.98.5.10.10 en 8 - 5
8
Support plate VS12D
Fig. 34: Support plate VS12D
Loosen star knob on guide element.
Remove support plate in an upward di-
rection.
Place the product holder on the car-
riage.
Product support VS12D-V
Fig. 35: Product support VS12D-V
Loosen star knob on guide element.
Remove product support.
Product holder, complete VS12D-V
Fig. 36: Product holder VS12D-V
Loosen star knob.
Remove complete product holder in up-
ward direction.
