BK Precision 2190E - Front Panel Description

2
Verify that all items above are included in the shipping container. If
anything is missing, please contact B&K Precision.
1.3 Front Panel
It is important for you to familiarize yourself with the DSO’s front panel
before operating the instrument. Below is a brief introduction of the front
panel function operation.
Figure 1.1 – Front Panel
Front Panel Description
Front USB (Type A) Connector
Menu Function Keys, Menu On/Off, Print Key
Input Channels (1 MΩ BNC)
Probe Compensator (1 kHz and Ground)
1
2
3
4
6
7
8
9
5
10
1
2
3
4
