79
Set up Grid
Press the “Grid” option button to select “ ”, “ ”or“
”to set the screen whether display grid or not.
Set up Menu Display
Press the “Menu Display” option button to select “2 sec”, “5sec”,
“10sec”, “20sec” or “Infinite” to set menu display time on screen.
Set Skin
Press the “skin” option button or turn the “Universal” knob to select
“Classical”, “Modern”, “Traditional” or “Succinct”.
X-Y Format
Use the XY format to analyze phase differences, such as those represented
by Lissajous patterns. The format plots the voltage on channel 1 against
the voltage on channel 2, where channel 1 is the horizontal axis and
channel 2 is the vertical axis. The oscilloscope uses the untriggered Sample
acquisition mode and displays data as dots.
NOTE: The oscilloscope can capture a waveform in normal YT mode
at any sampling rate. You can view the same waveform in XY mode.
To do so, stop the acquisition and change the display format to XY.
Operation steps:
Channel 1 “Volt/div” and vertical “POSITION” set up the
horizontal scale and position.
Channel 2 “Volt/div” and vertical “POSITION” set up the
horizontal scale and position.
Turn the “Time/div” knob to adjust the sampling rate
The following functions are forbidden in XY display form:
o Benchmark wave form and wave mathematic
o Cursor
o Auto (resets display format to YT)
o Trigger Control
