BK Precision 2190E User Manual

149
7 Specifications
All specifications apply to measurements with a 10X probe. To verify that
the oscilloscope meets specifications, the oscilloscope must first meet the
following conditions:
 The oscilloscope must have been operating continuously for 30
minutes within the specified operating temperature.
 You must perform the Do Self Cal operation, accessible through
the Utility menu, if the operating temperature changes by more
than 5° C.
 The oscilloscope must be within the factory calibration interval.
All specifications are guaranteed unless noted “typical.”
2190E
Inputs
Input Coupling
AC, DC, GND
Input Impedance
1 MΩ ± 2% || 16 pF ± 3 pF,
Maximum Input
voltage
400 V (DC+AC PK-PK, 1 MΩ input impedance,
X10), CAT I
Ch to Ch Isolation
(Both channels in
same V/div setting)
>100:1 at 100 MHz
Probe Attenuator
1X, 10X
Probe Attenuator
Factors Set
1X, 5X, 10X, 50X, 100X, 500X, 1000X
Vertical System
Vertical Sensitivity
2 mV/div -10 V/div (1-2-5 order)
Channel Voltage
Offset Range
2mV –200mV: ±1.6V 206mV - 10V: ±40V
Vertical Resolution
8 bit
Channels
2
Analog
Bandwidth (-3 dB)
100 MHz
