20
Language option
Saved reference waveform files
Saved setup files
Display contrast
Calibration data
Table 3.3 Default Setup Table
Menu or system
Options, knobs
or buttons
Default setup
CH1,CH2
Coupling
DC
BW limit
Off
Volts/div
Coarse
Probe
1X
Invert
Off
Filter
Off
Volts/div
1.00V
MATH
Operation
CH1+CH2
CH1 Invert
Off
CH2 Invert
Off
FFT operation:
Source
CH1
Window
Hanning
FFT Zoom
1X
Scale
dBVrms
Display
Split
HORIZONTAL
Window
Main
Position
0.00μs
Sec/div
500μs
Window Zone
50.0μs
Trigger knob
level
CURSOR
Type
Off
