22
Coupling
DC
LEVEL
0.00V
TRIGGER (pulse)
Type
pulse
Source
CH1
When
=
Set Pulse Width
1.00ms
Mode
Auto
Coupling
DC
TRIGGER (Video)
Type
Video
Source
CH1
Polarity
Normal
Sync
All Lines
Standard
NTSC
Mode
Auto
TRIGGER
(Slope)
Type
Slope
Source
CH1
Time
1.00ms
Mode
Auto
TRIGGER (Alternative)
Type
Alternative
Source
CH1
Mode
Edge
Coupling
DC
