26
Probe
1X, 5X
10X, 50X
100X, 500X,
1000X
Set to match the type of probe you
are using to ensure correct vertical
readouts.
Next Page
Page 1/3
Press this button to enter the second
page menu
Table 3.5 – Channel Function Menu 2
Option
Setting
Instruction
Invert
on
off
Turn on invert function.
Turn off invert function.
Filter
Press this button to enter the
“Digital Filter menu”.
Next Page
Page 2/3
Press this button to enter the third
page menu.
Table 3.6 – Channel Function Menu 3
Option
Setting
Introduction
Unit
V
A
Set the scale unit to voltage
Set the scale unit to current.
Skew
-100 ns –
100ns
Set the skew time between two
channels.
Next Page
Page 3/3
Press this button to return to the
first page menu.
